Item # 739.002
Key figures
- ultrawide input voltage range:22 ... 36 VDC
- very high efficiency:up to 95%
- peak input voltage:38 VDC
- output voltage / max. output current:92.3 VDC / 8.7 ADC
Applications
Galvanically isolated DC-DC converter for automotive applications with up to 800W power.
Galvanically isolated step-up DC-DC converter 24V to 92V with CC/CV characteristics.
The output voltage is 92VDC and is preset. The output voltage can be customized in a wide range (e.g. from 100V to 200V). The U/I characteristic can also be customized.
Product features
isolated DC/DC buck-boost converter
robust and climate proof design
excellent thermal characteristics
permanently no-load and short-circuit proof
integrated EMI input and output filter
no power derating
for ambient temperatures between -40°C / +85°C
thermal shutdown at +90°C
CC/CV charging characteristic
Areas of application
- Wind power
- Industrial trucks
- Warehouse management systems
- Rail transport
- Electromobility
- Mountain railways
- Battery-powered electrical systems
- Charging converter
- Universal
