Item # 334.002
Key figures
- ultrawide input voltage range:16 ... 160 VDC
- very high efficiency:up to 92%
- peak input voltage:170 VDC
- output voltage / max. output current:±24.0 VDC / ±1.0 ADC
Applications
Can be used as 48V-DC-Output while referencing the -24V-output to sencondary "Ground".
+12VDC/0/-12VDC bipolar version 334W-12012-SD available.
+15VDC/0/-15VDC bipolar version 334W-12012-SD available.
Product features
isolated DC/DC buck-boost converter
robust and climate proof design
excellent thermal characteristics
permanently no-load and short-circuit proof
integrated EMI input and output filter
no power derating
for ambient temperatures between -40°C / +85°C
thermal shutdown at +90°C
CC/CV charging characteristic
bipolar or doubled output
Areas of application
- Wind power
- Industrial trucks
- Warehouse management systems
- Rail transport
- Electromobility
- Mountain railways
- Battery-powered electrical systems
- Charging converter
- Universal
